Description

Typical 10ms fast transition to backup mode during power outage

< 2 Hours (5kW/5kWh system) high ef ciency circulation for charging and discharging

Midea EMS Supports Maximum Self-sufficiency

[Full specifications]

Input (PV)
Max. PV Power (kW) 9
Max. PV voltage (V) 550

Input (BAT)
Compatible battery type Lithium/Lead-acid
Battery voltage range(V) 40-60

Output (Grid)
Rated AC voltage (V) 230
Power factor >0.99@rated power(adjustable 0.8LG~0.8LD)

Efficiency
Max. efficiency (PV to AC) 97.30%
Max. efficiency (AC to BAT) 94.00%

General data
Max. operation altitude(m) 4000
Noise emission (dB) <35
Operating temperature range(°C) -25~60
Dimensions (W*H*D) (mm) 515*487*175

Click here to download  Manual
