Description

Safe & Reliable by Lithium Iron Phosphate (LFP) Cell

Individual BMS ensuring each battery work independently

mV level BMS accurate management ensuring 100% consistent charging and discharging during long-term operation

Stacks capacity from 5.0kWh to 90.0kWh

With each stack supporting maximum 30.0kWh to save space

[Full Specifications]

Depth of Discharge 100%
Charging Temp . Range (℃) 0~55
Discharging Temp . Range (℃) -20~55
Communication RS485/CAN
Calendar Life ≥6000 Cycles
Protection Level IP65
Color White
Protection Overcharge/Over discharge/Overcurrent/Overtemperature/Short Circuit
Pros Can be used in both off-grid and hybrid setups, compact design, modular expansion
Module Connection Method Parallel
Mounting Method Floor-standing
Certification CE/UN38.3/IEC62619
Max. Operating Altitude (m) 2000

Click here to download Manual
